New Garrett GT4088 Turbo DAF F75 Truck 9.2L PF230M PF235M Diesel 452231-5001
New Garrett GT4088 Turbo DAF F75 Truck 9.2L PF230M PF235M Diesel 452231-5001
SKU:452231-5001
Precio habitual
$1,728.00
Precio habitual
Precio de oferta
$1,728.00
Los gastos de envío se calculan en la pantalla de pago.
Cantidad
No se pudo cargar la disponibilidad de retiro
Orders ship Monday-Friday, usually within 24 hours of purchase.
International shipping subject to VAT and/or other import tax calculated during checkout.
BRAND NEW GENUINE GARRETT TURBOCHARGER
This is a BRAND NEW GENUINE GARRETT TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.
Fits the following:
Part Number: 452231-5001
Interchangeable Number: 452231-0001, 452231-5001S
OEM Number: 1311280
Turbo Model: GT4088
Brand: Honeywell - Garrett
Engine: PE235, PF205M, PF230M, PF235M
Engine Manufacturer: DAF
Displacement: 9.2L, 9200 ccm, 6 Cylinders
Fuel: Diesel
Power: 313 hp
Angle α (Compressor Housing): 205°
Angle β (Turbine Housing): 120°
Back Plate: 436019-0012 (436019-0006)(1300016110)
Bearing Housing: 448316-0001 (448316-0019)(Oil Cooled)(1900011249)
CHRA: 449739-0012 (449739-5012S)(1000010247)
Compressor Housing: 413618-0004
Compressor Wheel: 449521-0007 (Ind. 64.56 mm, Exd. 88.19 mm, Trim 54, 6+6 Blades, Threaded Bore Type, Super Back)(1200016353)
Gasket (Oil Inlet): 129119 (201049, 9737, 1S6595, 210019-0000, 409266-0003, 3819900)(1900000035)
Gasket (Oil Outlet): 210060 (311585, 148062, 2475013)(Paper)
Gasket (Turbine Inlet): 409123-0002 (310694)(Inox Steel)
Gasket (Turbine Outlet): 210221 (Stainless Steel)
Gasket Kit: 215109
Heat Shield: 448294-0001 (2030016014)
Repair Kit: 709152-0001 (1102040751, 5000010081B)
Turbine Housing A/R: 1.19
Turbine Housing: 434309-0089
Turbine Wheel: 449022-0013 (Ind. 77.2 mm, Exd. 70.7 mm, Trim 14.8, 10 Blades)(1100016267)
Turbo Technology: Free Floating
Application:
1996- DAF 75CF 320 Truck with 9.2L PF235M Diesel Engine
1996- DAF F75 Truck with 9.2L PF205M, PF230M, PF235M Diesel Engine
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
