New Garrett TV8112 Turbo CAT Industrial 27.0L 3412 3412E Diesel 465332-5012
New Garrett TV8112 Turbo CAT Industrial 27.0L 3412 3412E Diesel 465332-5012
SKU:465332-5012
Precio habitual
$1,650.00
Precio habitual
Precio de oferta
$1,650.00
Los gastos de envío se calculan en la pantalla de pago.
Cantidad
No se pudo cargar la disponibilidad de retiro
Orders ship Monday-Friday, usually within 24 hours of purchase.
International shipping subject to VAT and/or other import tax calculated during checkout.
BRAND NEW GENUINE GARRETT TURBOCHARGER
This is a BRAND NEW GENUINE GARRETT TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.
Fits the following:
Part Number: 465332-5012
Interchangeable Number: 465332-0012, 465332-5012S, 465332-0006, 465332-5006, 465332-5006S, 465332-0007, 465332-5007, 465332-5007S, 465332-0011, 465332-5011, 465332-5011S
OEM Number: 0R-7104, 0R7104, 0R-7219, 0R7219, 134-3592, 1343592, 144-4568, 1444568, 1W-6931, 1W6931, 1W-6932, 1W6932
Turbo Model: TV8112
Brand: Honeywell - Garrett
Engine: 3406, 3412, 3412C, 3412E, PM3412
Engine Manufacturer: Caterpillar
Displacement: 14.6L, 14600 ccm, 6 Cylinders (3406), 27.0L, 27000 ccm, 12 Cylinders (3412, 3412C, 3412E, PM3412)
Fuel: Diesel
Power: 1052 hp
Speed: 1500 rpm
Prefix: 38S, 4BZ, 4CR, 5FL, 5XC, 7CK, 81Z, 8AC, 9EP, BAX, BCW, BDT, BGE, LRY
Back Plate: 408487-0013 (6N7962)(180043-0000)(1101680360)
Bearing Housing: 408495-0028 (408495-0009, 408495-0010)(9N2035)(Oil Cooled)(1101672450)
CHRA: 408742-0011 (408742-5011S, 408742-0036, 408742-5036S, 408742-0080, 408742-5080S, 0R5926, 0R7105, 134-3668, 1343668, 1N4356, 9N3676, 180024-0000)(1101081707)
Compressor Housing: 409168-0189 (1343777)
Compressor Wheel: 409132-0004 (134-3668, 9N3674)(444827-0018, 444827-0004, 180019-0000)(Ind. 72.59 mm, Exd. 107.95 mm, 6+6 Blades, Super Back)(1101081403)
Gasket (Oil Inlet): 210019 (409266-0003, 3819900, 9737, 1S6595, 201049, 129119)(1900000035)
Gasket (Oil Outlet): 210018 (409267-0002, 1S4810, 3519763, 3500682, 3709738, 9738, 9988, 201048, 129120)(1900000025)
Gasket (Turbine Inlet): 409038-0000 (132040, 1S4295, 202873, 205396, 9749, 3500683, 210017-0000)(1900000003)
Gasket Kit: 215120
Heat Shield: 407657-0004 (9N2037, 9N3701)(409794-0000, 409794-0001, 180021-0000, 180121-0000)(1101680340, 1300016142)
Repair Kit: 468211-0000 (468103-0000, 3545836, 188002-0000)
Turbine Housing A/R: 1.08
Turbine Housing: 408499-0033 (1W6933)
Turbine Wheel: 408492-0022 (408492-0012, 408492-0018, 408492-0016, 408492-0023)(0R5393, 6N4606)(Ind. 111.4 mm, Exd. 87.73 mm, Trim 13.35, 11 Blades)(1101081436)
Turbo Technology: Free Floating
Application:
Caterpillar Construction Equipment with 27.0L 3412 Diesel Engine
Caterpillar Earth Moving with 14.6L 3406 Diesel Engine
Caterpillar Earth Moving with 27.0L 3412 Diesel Engine
Caterpillar Industrial with 14.6L 3406 Diesel Engine
Caterpillar Industrial with 27.0L 3412, 3412E Diesel Engine
Caterpillar Marine with 14.6L 3406 Diesel Engine
Caterpillar Marine with 27.0L 3412 Diesel Engine
Caterpillar SR4 Generator with 27.0L 3412, 3412C, PM3412 Diesel Engine
Caterpillar Various with 14.6L 3406 Diesel Engine
Caterpillar Various with 27.0L 3412, 3412C, 3412E Diesel Engine
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
This is a BRAND NEW GENUINE GARRETT TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.
Fits the following:
Part Number: 465332-5012
Interchangeable Number: 465332-0012, 465332-5012S, 465332-0006, 465332-5006, 465332-5006S, 465332-0007, 465332-5007, 465332-5007S, 465332-0011, 465332-5011, 465332-5011S
OEM Number: 0R-7104, 0R7104, 0R-7219, 0R7219, 134-3592, 1343592, 144-4568, 1444568, 1W-6931, 1W6931, 1W-6932, 1W6932
Turbo Model: TV8112
Brand: Honeywell - Garrett
Engine: 3406, 3412, 3412C, 3412E, PM3412
Engine Manufacturer: Caterpillar
Displacement: 14.6L, 14600 ccm, 6 Cylinders (3406), 27.0L, 27000 ccm, 12 Cylinders (3412, 3412C, 3412E, PM3412)
Fuel: Diesel
Power: 1052 hp
Speed: 1500 rpm
Prefix: 38S, 4BZ, 4CR, 5FL, 5XC, 7CK, 81Z, 8AC, 9EP, BAX, BCW, BDT, BGE, LRY
Back Plate: 408487-0013 (6N7962)(180043-0000)(1101680360)
Bearing Housing: 408495-0028 (408495-0009, 408495-0010)(9N2035)(Oil Cooled)(1101672450)
CHRA: 408742-0011 (408742-5011S, 408742-0036, 408742-5036S, 408742-0080, 408742-5080S, 0R5926, 0R7105, 134-3668, 1343668, 1N4356, 9N3676, 180024-0000)(1101081707)
Compressor Housing: 409168-0189 (1343777)
Compressor Wheel: 409132-0004 (134-3668, 9N3674)(444827-0018, 444827-0004, 180019-0000)(Ind. 72.59 mm, Exd. 107.95 mm, 6+6 Blades, Super Back)(1101081403)
Gasket (Oil Inlet): 210019 (409266-0003, 3819900, 9737, 1S6595, 201049, 129119)(1900000035)
Gasket (Oil Outlet): 210018 (409267-0002, 1S4810, 3519763, 3500682, 3709738, 9738, 9988, 201048, 129120)(1900000025)
Gasket (Turbine Inlet): 409038-0000 (132040, 1S4295, 202873, 205396, 9749, 3500683, 210017-0000)(1900000003)
Gasket Kit: 215120
Heat Shield: 407657-0004 (9N2037, 9N3701)(409794-0000, 409794-0001, 180021-0000, 180121-0000)(1101680340, 1300016142)
Repair Kit: 468211-0000 (468103-0000, 3545836, 188002-0000)
Turbine Housing A/R: 1.08
Turbine Housing: 408499-0033 (1W6933)
Turbine Wheel: 408492-0022 (408492-0012, 408492-0018, 408492-0016, 408492-0023)(0R5393, 6N4606)(Ind. 111.4 mm, Exd. 87.73 mm, Trim 13.35, 11 Blades)(1101081436)
Turbo Technology: Free Floating
Application:
Caterpillar Construction Equipment with 27.0L 3412 Diesel Engine
Caterpillar Earth Moving with 14.6L 3406 Diesel Engine
Caterpillar Earth Moving with 27.0L 3412 Diesel Engine
Caterpillar Industrial with 14.6L 3406 Diesel Engine
Caterpillar Industrial with 27.0L 3412, 3412E Diesel Engine
Caterpillar Marine with 14.6L 3406 Diesel Engine
Caterpillar Marine with 27.0L 3412 Diesel Engine
Caterpillar SR4 Generator with 27.0L 3412, 3412C, PM3412 Diesel Engine
Caterpillar Various with 14.6L 3406 Diesel Engine
Caterpillar Various with 27.0L 3412, 3412C, 3412E Diesel Engine
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
