New Garrett GT6041BL Turbo CAT Genset Industrial Marine 3512B 51.8L 709265-5006

BRAND NEW GENUINE GARRETT TURBOCHARGER

This is a BRAND NEW GENUINE GARRETT TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.

Fits the following:

Part Number: 709265-5006
Interchangeable Number: 471094-9002, 4710949002, 700245-9001, 7002459001, 709265-0004, 709265-5001, 709265-5005, 709265-9002, 709265-9006, 7092650004, 7092655001, 7092655005, 7092659002, 7092659006, 471094-0002, 4710940002, 700245-0001, 7002450001, 709265-0001, 709265-0005, 709265-5002, 709265-5006, 709265-9004, 7092650001, 7092650005, 7092655002, 7092655006, 7092659004, 471094-5002, 4710945002, 700245-5001, 7002455001, 709265-0002, 709265-0006, 709265-5004, 709265-9001, 709265-9005, 7092650002, 7092650006, 7092655004, 7092659001, 7092659005
OEM Number: 0R-7119, 0R7119, 122-0700, 1400393, 1700251625, 175-5208, 1805435, 0R-7312, 0R7312, 1220700, 169-2566, 174-7090, 1755208, 305-2681, 0R-7430, 0R7430, 140-0393, 1692566, 1747090, 180-5435, 3052681
Turbo Model: GT6041BL
Brand: Honeywell - Garrett

Engine: 3512B
Engine Manufacturer: Caterpillar
Displacement: 51.8L, V-12 diesel engine
Fuel: Diesel
Power: 1650 hp

Bearing Housing 451488-0001 (Water Cooled)
Turbine Wheel 451447-0001 (Ind. 113. mm, Exd. 130. mm, Trm 21.6, 11 Blades)
Comp. Wheel 452702-0009 (452702-0001)(Ind. 97.8 mm, Exd. 141.28 mm, 6+6 Blades)
Back plate 452703-0001
Repair Kit 705731-0001
CHRA: 452705-5040S
Turbine Housing 442630-0054 (1207534, 1524981, 2521714, 2942942)
Compressor Cover 451839-0003 (1313100, 1783655)
Gasket (turbine inlet) 409038-0001 (1215736, 7M7273)
Gasket oil inlet 210019 (129119)
Gasket (oil outlet) 210018 (129120)

Application:
Caterpillar Off-Highway Truck 785B, 785C, 784C, 777D, 3512B
Caterpillar Genset with CAT 3512B 51.8L Diesel Engine
Caterpillar Industrial Locomotive Engine with CAT 3512B 51.8L Diesel Engine
Caterpillar Tractor with CAT 3512B 51.8L Diesel Engine

*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
