NEW Garrett GT4088VA Turbo International NGV Truck I319 8.7L Diesel 724193-5005
NEW Garrett GT4088VA Turbo International NGV Truck I319 8.7L Diesel 724193-5005
SKU:724193-5005
Precio habitual
$3,195.00
Precio habitual
$0.00
Precio de oferta
$3,195.00
Los gastos de envío se calculan en la pantalla de pago.
Cantidad
No se pudo cargar la disponibilidad de retiro
Orders ship Monday-Friday, usually within 24 hours of purchase.
International shipping subject to VAT and/or other import tax calculated during checkout.
BRAND NEW GENUINE GARRETT TURBOCHARGER
This is a BRAND NEW GENUINE GARRETT TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.
Fits the following:
Part Number: 724193-5005
Interchangeable Number: 724193-0005, 724193-5005S, 724193-0001, 724193-5001, 724193-5001S
OEM Number: 1833420C91, 1833420C93, 1841283C91, 1841283C92, 1841283C93, 2596972C91, 4307249R91, 500\060, 500060, 500\549, 500549
Turbo Model: GT4088VA
Manufacturer: Honeywell-Garrett
Year: 2002-
Engine: DT466E, DT530E, I319
Engine Manufacturer: Navistar
Displacement: 8.7L, 8700 ccm, 6 Cylinders
Emission Standard: Tier 4f
Fuel: Diesel
Power: 340 HP
Speed: 2000 RPM
Angle α (Compressor Housing): 242.5°
Angle β (Turbine Housing): 0.58°
Actuation: Electro-Hydraulic
Back Plate: 725488-0001
Bearing Housing: 720780-0054 (Oil Cooled)
CHRA: 720781-0007 (720781-5007S)
Compressor Cover: 449633-0039
Compressor Wheel: 449521-0018 (Ind. 34.08 mm, Exd. 46.02 mm, Trim 4.31, 6+6 Blades, Super Back)
Electro-Hydraulic Valve: 792593-0001 (711122-0008, 711122-0013, 711122-0016, 711122-0017, 726473-0001, 726473-0002, 726473-0003)(5C3Z-6F089-A, 5C3Z-6F089-AA, 5C3Z-6F089-B, 5C3Z-6F089-BA, 5C3Z6F089A, 5C3Z6F089AA, 5C3Z6F089B, 5C3Z6F089BA, 1838525C1, 1841228C91, 1855683C91, 1855684C1, 1876070C91, 2N-6001VGS, 2N6001VGS, 5101-137-002, 5101137002, 811-0111, 8110111, 97376382, 97387888, 98061571, ISK852)
Gasket (Oil Inlet): 210023 (210023-0000, 147837, 210021, 215234, 55739, 3709737, 3500681, 3519762, 409266-0001, 409036-0000, 409026-0001, 52231586500)(1900000037)(Paper)
Gasket (Turbine Inlet): 407294-0001 (310694, 303031063, 166618C, 8A0709, A58899, E5HN6N640AA, E7HZ6N640A, T30820, 312617)(Stainless Steel)
Heat Shield: 720416-0006
Turbine Housing & Nozzle Assembly: 726405-0004
Turbine Housing A/R: 0.90
Turbine Wheel: 717115-0004 (Ind. 68 mm, Exd. 76 mm, Trim 15, 10 Blades)
Turbo Technology: AVNT
Application:
2002- International New Generation Vehicle (NGV) Severe Service, Truck with Navistar I319 Engine
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
This is a BRAND NEW GENUINE GARRETT TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.
Fits the following:
Part Number: 724193-5005
Interchangeable Number: 724193-0005, 724193-5005S, 724193-0001, 724193-5001, 724193-5001S
OEM Number: 1833420C91, 1833420C93, 1841283C91, 1841283C92, 1841283C93, 2596972C91, 4307249R91, 500\060, 500060, 500\549, 500549
Turbo Model: GT4088VA
Manufacturer: Honeywell-Garrett
Year: 2002-
Engine: DT466E, DT530E, I319
Engine Manufacturer: Navistar
Displacement: 8.7L, 8700 ccm, 6 Cylinders
Emission Standard: Tier 4f
Fuel: Diesel
Power: 340 HP
Speed: 2000 RPM
Angle α (Compressor Housing): 242.5°
Angle β (Turbine Housing): 0.58°
Actuation: Electro-Hydraulic
Back Plate: 725488-0001
Bearing Housing: 720780-0054 (Oil Cooled)
CHRA: 720781-0007 (720781-5007S)
Compressor Cover: 449633-0039
Compressor Wheel: 449521-0018 (Ind. 34.08 mm, Exd. 46.02 mm, Trim 4.31, 6+6 Blades, Super Back)
Electro-Hydraulic Valve: 792593-0001 (711122-0008, 711122-0013, 711122-0016, 711122-0017, 726473-0001, 726473-0002, 726473-0003)(5C3Z-6F089-A, 5C3Z-6F089-AA, 5C3Z-6F089-B, 5C3Z-6F089-BA, 5C3Z6F089A, 5C3Z6F089AA, 5C3Z6F089B, 5C3Z6F089BA, 1838525C1, 1841228C91, 1855683C91, 1855684C1, 1876070C91, 2N-6001VGS, 2N6001VGS, 5101-137-002, 5101137002, 811-0111, 8110111, 97376382, 97387888, 98061571, ISK852)
Gasket (Oil Inlet): 210023 (210023-0000, 147837, 210021, 215234, 55739, 3709737, 3500681, 3519762, 409266-0001, 409036-0000, 409026-0001, 52231586500)(1900000037)(Paper)
Gasket (Turbine Inlet): 407294-0001 (310694, 303031063, 166618C, 8A0709, A58899, E5HN6N640AA, E7HZ6N640A, T30820, 312617)(Stainless Steel)
Heat Shield: 720416-0006
Turbine Housing & Nozzle Assembly: 726405-0004
Turbine Housing A/R: 0.90
Turbine Wheel: 717115-0004 (Ind. 68 mm, Exd. 76 mm, Trim 15, 10 Blades)
Turbo Technology: AVNT
Application:
2002- International New Generation Vehicle (NGV) Severe Service, Truck with Navistar I319 Engine
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
