TD06H Turbo for Hyundai Crawler CAT Excavator 3066 Diesel Engine 49179-02350
TD06H Turbo for Hyundai Crawler CAT Excavator 3066 Diesel Engine 49179-02350
SKU:F49179-02350
Precio habitual
$829.00
Precio habitual
$0.00
Precio de oferta
$829.00
Los gastos de envío se calculan en la pantalla de pago.
Cantidad
No se pudo cargar la disponibilidad de retiro
Orders ship Monday-Friday, usually within 24 hours of purchase.
International shipping subject to VAT and/or other import tax calculated during checkout.
TURBOTURBOS REMANUFACTURED TURBOCHARGER
This is a TURBOTURBOS REMANUFACTURED TURBOCHARGER. This is an exact, direct fit replacement turbo.
Fits the following:
Part Number: 49179-02350
Interchangeable Number: 4917902350, 316375, 49179-02300, 4917902300, 49179-02340, 4917902340, 49179-02360, 4917902360, 49179-02370, 4917902370, 49179-02390, 4917902390, 49S79-02300, 49S7902300, 49S79-02350, 49S7902350, 49S79-A2340, 49S79A2340
OEM Number: 205-6741, 2056741, 222-8219, 2228219, 227-1027, 2271027, 279-7860, 2797860, 5I-8018, 5I8018, ME2056741
Turbo Model: TD06H, TD06H-16M-12.0
Engine: 3066, 3066T, C6.4, S6K, S6K-T, S6S-DT, S6S-Y2DT, S6S-Y2DT61HS
Displacement: 6.4L
Fuel: Diesel
Back Plate: 49168-22500 (197340)(1352351)(2455007)
Bearing Housing: 49179-20300 (1352359)(Oil Cooled)
CHRA: 49179-08600 (316402)(5I7589, 5I-7589)
Compressor Housing: 49179-57860/443213-0020 (5I7587)
Compressor Wheel: 49185-40700 (1352360)(Ind. 48.04 mm, Exd. 68.01 mm, 6+6 Blades)
Cooling: Air
Gasket (Oil Outlet): 210317 (5I7689)(Paper)
Gasket (Turbine Inlet): 409039-0001/409039-0000 (210022-0000, 2405022)(5I7742)
Heat Shield: 49168-18900 (193975, 1352346)
Repair Kit: 49178-80030/49178-81100 (49178-89200)(2455063)(1401405750)
Turbine Housing A/R: 12.0
Turbine Housing: 49179-17821/49179-17822/49179-17820 (5I8041)
Turbine Wheel: 49179-30220 (1352357)(Ind. 58.8 mm, Exd. 68 mm, 12 Blades)
Application:
Caterpillar 320, 320B L, 320B LL, 320B LU, 320B N, 320B U, 320B, 320C L, 320C, 320D L, 320D LRR, 320D RR, 320D, 321B, 321C, 323D L, 323D LN, 323D S, E320 Hydraulic Excavator, Earth Moving with 3066, 3066T, C6.4, S6K Engine
Hyundai 320 Excavator, Crawler with 3066 Engine
Hyundai 7 Series Crawler Excavator
Hyundai R160-7, R160-9S, R170W-7, R170W-9S, R180-7, R180-9S, R180W-9S Wheel Excavator
Hyundai R160LC-7, R180LC-7 Crawler Excavator
Mitsubishi, Caterpillar Construction with S6K, S6K-T, S6S-Y2DT Engine
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
This is a TURBOTURBOS REMANUFACTURED TURBOCHARGER. This is an exact, direct fit replacement turbo.
Fits the following:
Part Number: 49179-02350
Interchangeable Number: 4917902350, 316375, 49179-02300, 4917902300, 49179-02340, 4917902340, 49179-02360, 4917902360, 49179-02370, 4917902370, 49179-02390, 4917902390, 49S79-02300, 49S7902300, 49S79-02350, 49S7902350, 49S79-A2340, 49S79A2340
OEM Number: 205-6741, 2056741, 222-8219, 2228219, 227-1027, 2271027, 279-7860, 2797860, 5I-8018, 5I8018, ME2056741
Turbo Model: TD06H, TD06H-16M-12.0
Engine: 3066, 3066T, C6.4, S6K, S6K-T, S6S-DT, S6S-Y2DT, S6S-Y2DT61HS
Displacement: 6.4L
Fuel: Diesel
Back Plate: 49168-22500 (197340)(1352351)(2455007)
Bearing Housing: 49179-20300 (1352359)(Oil Cooled)
CHRA: 49179-08600 (316402)(5I7589, 5I-7589)
Compressor Housing: 49179-57860/443213-0020 (5I7587)
Compressor Wheel: 49185-40700 (1352360)(Ind. 48.04 mm, Exd. 68.01 mm, 6+6 Blades)
Cooling: Air
Gasket (Oil Outlet): 210317 (5I7689)(Paper)
Gasket (Turbine Inlet): 409039-0001/409039-0000 (210022-0000, 2405022)(5I7742)
Heat Shield: 49168-18900 (193975, 1352346)
Repair Kit: 49178-80030/49178-81100 (49178-89200)(2455063)(1401405750)
Turbine Housing A/R: 12.0
Turbine Housing: 49179-17821/49179-17822/49179-17820 (5I8041)
Turbine Wheel: 49179-30220 (1352357)(Ind. 58.8 mm, Exd. 68 mm, 12 Blades)
Application:
Caterpillar 320, 320B L, 320B LL, 320B LU, 320B N, 320B U, 320B, 320C L, 320C, 320D L, 320D LRR, 320D RR, 320D, 321B, 321C, 323D L, 323D LN, 323D S, E320 Hydraulic Excavator, Earth Moving with 3066, 3066T, C6.4, S6K Engine
Hyundai 320 Excavator, Crawler with 3066 Engine
Hyundai 7 Series Crawler Excavator
Hyundai R160-7, R160-9S, R170W-7, R170W-9S, R180-7, R180-9S, R180W-9S Wheel Excavator
Hyundai R160LC-7, R180LC-7 Crawler Excavator
Mitsubishi, Caterpillar Construction with S6K, S6K-T, S6S-Y2DT Engine
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
