NEW HX40W Turbo Truck Transit Bus Cummins Pegasus ISC 8.3L 4033650 4046058

BRAND NEW TURBOTURBOS TURBOCHARGER

This is a BRAND NEW TURBOTURBOS TURBOCHARGER. This is an exact, direct fit replacement turbo.

NOTE: This turbocharger is missing the temperature sensor, but comes with the gaskets.

Fits the following:

Part Number: 4046058
Interchangeable Number: 2842810, 3536333, 4033649H, 4033649HX, 4033650H, 4033650HX, 4036429, 4036654, 4036655H, 4036655HX, 4039905, 4039918, 4039919H, 4039919HX, 4039920, 4039921H, 4039921HX, 4089825, 4089839, 4089839NX, 4089839RX, 408992700, 408992700HX, 4089927HX, 4089927NX, 4089927RX
OEM Number: 3536334, 3536335, 3537884, 3802769, 4033649, 4033650, 4033657, 4036430, 4036655, 4036657, 4037721, 4038708, 4039906, 4039907, 4039908, 4039909, 4039910, 4039919, 4039921, 4089927
Turbo Model: HX40W

Engine: ISC, Pegasus ISC
Engine Manufacturer: Cummins
Displacement: 8.3L
Fuel: Diesel

Angle α (Compressor Housing): 176/195/212/275°
Angle β (Turbine Housing): 60/133/157°
Actuator Kit (Pneumatic): 4031329H
Bearing Housing: 4038197 (4038197H, 3537112, 3593878)(Oil Cooled)
CHRA: 4031321 (4031321H, 4032234, 4032695, 4043363)
Clamp Plate (Turbine): 2839879H
Compressor Housing Assy: 4036382H
Compressor Wheel: 4035879 (3599016, 4035879, 4043377)(Ind. 59.99 mm, Exd. 86.05 mm, Trim 5.86, 7+7 Blades, Super Back)(1154351400)
Gasket (Oil Inlet): 409039-0000 (409039-0001, 210022-0000, 210019, 312617, 2405022, 7C7431)(1900000006)(Inox Steel)
Gasket (Oil Outlet): 210060 (2475013, 409267-0003, 409267-0002, 210060-0000, 51914, 148062, 311585)(Paper)
Gasket Kit: 3545575 (1900100057)
Heat Shield: 3519302 (3519304)(1152301340)
Repair Kit (Major): 3575169H/4027448H
Repair Kit (Minor): 4031746H
Retaining Ring: 3533163H
Seal Plate: 3596448 (3530923)
Split Ring Seal (Compressor): 3758848H
Temperature Sensor: 4088833/4088833H
Turbine Housing Kit: 3591164H
Turbine Wheel: 3596226 (3596226H, 4050572)(Ind. 64 mm, Exd. 76 mm, Trim 10.16, 10 Blades)
Turbocharger Kit: 4033650H/4033650HX

Application:
2004- Transit Bus with Cummins Pegasus ISC Engine
2004- Truck with Cummins Pegasus ISC Engine
Automotive with Cummins ISC Engine

TurboTurbos Part Number: TP05-0263-36

*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
