Remanufactured Holset HE500VG Turbo Daimler Fire Truck Series 60 14.0L 3786234HX

OEM REMANUFACTURED HOLSET TURBOCHARGER

This is a OEM REMANUFACTURED HOLSET TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.

Fits the following:

Part Number: 3786234HX
Interchangeable Number: 2836825, 2836826, 3781168, 3781169, 378623400, 378623400H, 378623400HX, 3786234H, 3792071, 3798597, 4047269, 5329513, 5352845, 5352846, 5498208
OEM Number: 19514480D, 23536422, 23536802, 23539062, 23539570, 3786234, 3792069, 4045291, 4047598, AP80055, E23536422, E23539062, E23539570, R23536422, R23539062, R23539570
Serial Number: 1209197011
Turbo Model: HE500VG, HE531VE
Manufacturer: Holset

Year: 2004-14
Engine: Series 60 (VGT) on EPA07
Engine Manufacturer: Detroit Diesel, MTU Detroit Diesel
Displacement: 14.0L, 14000 ccm
Fuel: Diesel

Angle α (Compressor Housing): 194°
Angle β (Turbine Housing): 90°
Actuator Installation Kit: 4031365 (20837312, 23537048, 403136500H, 4031365H)
Actuator Kit: 4034121 (3787580, 3787582, 4032244, 403412100, 403412100H, 4034121H, 23537677, E23537677, R23537677, 4034120H, AP80082, 4042309, 5352847)(12 Volts)
Bearing Housing: (Oil cooled)
CHRA: 4034440 (4034440H)
Compressor Wheel: 4035068 (2836825)(Ind. 65.19 mm, Exd. 98.61 mm, Trim 6.30, 7+7 Blades, Super Back)
Gasket Kit: 3545576 (201049, 3519763)
Nozzle Ring Assembly: (1154500990)
Repair Kit: (1154500755)
Turbine Housing A/R: VI EGR
Turbine Wheel: 4042581 (Ind. 83.99 mm, Exd. 69.97 mm, 12 Blades)(1154055438, 1100016492)

Application:
2004-14 Daimler Fire Truck (Class 3-8), Various with Detroit Diesel Series 60 Engine
Kenworth, Peterbilt, Freightliner with Detroit Diesel Series 60 Engine

*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
