NEW OEM Garrett TA3123 Turbo CAT 3054 Perkins Industrial 1004 4.0L 466674-5004

BRAND NEW GENUINE GARRETT TURBOCHARGER

This is a BRAND NEW GENUINE GARRETT TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.

Fits the following:

Part Number: 466674-5004
Interchangeable Number: 466674-0004, 466674-5004S, 466674-0006, 466674-5006, 466674-5006S
OEM Number: 0R-9512, 0R9512, 118-8384, 1188384, 2674400, 2674A301, U2674A301
Turbo Model: TA3123
Manufacturer: Honeywell-Garrett

Year: 1992-
Engine: 1004, 1004-4T, 3054, 3054T
Displacement: 4.0L, 4000 ccm, 4 Cylinders
Fuel: Diesel
Power: 110 HP
Speed: 2600 RPM

Angle α (Compressor Housing): 180°
Angle β (Turbine Housing): 120°
Back Plate: 409629-0004 (197340)(1100030301, 1300016007)
Bearing Housing: 430027-0025 (312379, 407285-0027, 407285-0038, 430027-0022, 430027-0048)(Oil Cooled)(1100030450, 1900011104B)
CHRA: 409172-0052 (409172-9052S)(6I4203)(1100030901)
Compressor Cover: 409115-0127 (311629)
Compressor Wheel: 409096-0008 (197611)(103016-0000, 409096-0001)(Ind. 40.51 mm, Exd. 60.09 mm, Trim 5.15, 6+6 Blades, Super Back)(1100030401, 1200030071)
Gasket (Oil Inlet): 210023 (210023-0000, 147837, 210021, 215234, 55739, 3709737, 3500681, 3519762, 409266-0001, 409036-0000, 409026-0001, 52231586500)(1900000037)
Gasket (Oil Outlet): 210021 (148062, 311496, 3519807, 413671-0000, 409037-0000)(1900000027)
Gasket (Turbine Inlet): 409039-0000 (409039-0001, 210019, 312617, 2405022, 7C7431)(1900000006)(Inox Steel)
Heat Shield: 409627-0000 (103121-0000, 409627-0001, 311131)(1100030340)
Repair Kit: 468139-0000 (79087623)(1100030765, 5000010041)
Turbine Housing A/R: 0.48
Turbine Housing: 409526-0002
Turbine Wheel: 451314-0001 (Ind. 50.5 mm, Exd. 64 mm, Trim 62, 11 Blades)(1100030439)
Turbo Technology: Free Floating

Application:
1992- Caterpillar 1000 Series, Industrial with 1004 Engine
1992- Perkins Industrial with 1004, 1004-4T Engine
Caterpillar 426C Backhoe Loader
Caterpillar CB534B, CB534C, CB535B, CP433C, CS431C, CS433C Vibratory Compactor Roller with 3054T Engine
Caterpillar PS-200B Pneumatic Compactor with 3054T Engine
Caterpillar TH62, TH63, TH82, TH83, TH103 Telehandler with 3054T Engine
Caterpillar Various with 3054 Engine

*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
