NEW OEM BorgWarner S410G Turbo CAT Truck Tractor 3406E 3406C C16 14.64L 177148

BRAND NEW GENUINE BORGWARNER TURBOCHARGER

This is a BRAND NEW GENUINE BORGWARNER TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.

Fits the following:

Part Number: 177148
Interchangeable Number: 169227, 170354, 466445-0015, 466445-5015, 466445-5015S, 466445-0018, 466445-5018, 466445-5018S, 466445-0021, 466445-5021, 466445-5021S, 466445-0023, 466445-5023, 466445-5023S, 471142-0003, 471142-5003, 471142-5003S, 471142-0005, 471142-5005, 471142-5005S, 704604-0007, 704604-5007, 704604-5007S, 704604-0011, 704604-5011, 704604-5011S
OEM Number: 0R-6986, 0R6986, 0R-6989, 0R6989, 0R-7152, 0R7152, 0R-7201, 0R7201, 0R-7203, 0R7203, 0R-7223, 0R7223, 0R-7299, 0R7299, 0R-7310, 0R7310, 0R-7923, 0R7923, 124-3032, 1243032, 124-3035, 1243035, 136-6390, 1366390, 137-4832, 1374832, 141-8937, 1418937, 141-8939, 1418939, 146-4328, 1464328, 160-6201, 1606201, 166-6752, 1666752, 167-9271, 1679271, 196-5951, 1965951, 222-1133, 2221133
Serial Number: OKC150148
Turbo Model: S410G
Manufacturer: BorgWarner - 3K - Schwitzer, BWTS USA

Year: 1994-08
Engine: 3406E, 3406C, C16
Displacement: 14.64L, 14640 ccm
Fuel: Diesel
Power: 317 kW/425 HP, 355 kW/475 HP, 404 kW/550 HP
Speed: 1800 RPM

Actuator: 446131-0046
Back Plate: 451444-0002
Bearing Housing: 451358-0004
CHRA: 174248 (161-6780, 10R-0510, 0R7287, 451686-0016)
Compressor Cover: 447992-0027/704569-0003 (161-6783)
Compressor Wheel: 451936-0001 (4P3818) (Ind. 74.57 mm, Exd. 105.3 mm)
Gasket (Oil Inlet): 210019 (129119)
Gasket (Oil Outlet): 210018 (129120)
Heat Shield: 707967-0002
Repair Kit: 176392
Turbine Housing + Actuator: 447990-0099 (221-2104)
Turbine Housing: 702908-0003, 1.32 A/R
Turbine Wheel: 702892-0001 (Ind. 91.46 mm, Exd. 81.66 mm)

Application:
1994-01 Caterpillar Truck with 3406E Engine
1994-07 Caterpillar Truck, Tractor with 3406E, 3406C, C16 Engine
1996-07 Caterpillar with 3406C (425 HP) Engine
1998-01 Caterpillar Truck with 3406E (435-550 HP), 3406E (455-550 HP) Engine
1998-08 Caterpillar with 3406E (Low HP) Engine
Caterpillar Truck with 3406E (425 HP), 3406E (475 HP) Engine
