NEW BorgWarner 4HD Turbo CAT Earth Moving D399 Generator SR4 178051 182781
NEW BorgWarner 4HD Turbo CAT Earth Moving D399 Generator SR4 178051 182781
SKU:178051
Regular price
$2,895.00
Regular price
Sale price
$2,895.00
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Orders ship Monday-Friday, usually within 24 hours of purchase.
International shipping subject to VAT and/or other import tax calculated during checkout.
BRAND NEW GENUINE BORGWARNER TURBOCHARGER
This is a BRAND NEW GENUINE BORGWARNER TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.
Fits the following:
Part Number: 182781
Interchangeable Number: 178051, 478051
OEM Number: 0R-5827, 0R5827, 2P-3176, 2P3176, 4N-4564, 4N4564, 6N-8460, 6N8460
Turbo Model: 4HD, 4HD-857
Brand: BorgWarner - 3K - Schwitzer
Engine: D399, SR4
Engine Manufacturer: Caterpillar
Fuel: Diesel
Angle α (Compressor Housing): 107°
Angle β (Turbine Housing): 90°
Bearing Housing Insert: 139053
Bearing Housing: 137568 (0R5399, 2S1309, 4N4042, 9M9929)(Oil Cooled)
CHRA: 157702 (310145, 0R5883, 4N4041, 6N8658, 157702R, 178141, 457702, 478141)
Compressor Housing: 143971 (5S3974)
Compressor Wheel: 140922 (139398)(5S3975)(Ind. 78.8 mm, Exd. 122 mm, Trim 7.56, 7+7 Blades, Super Back)
Filter Cup: 183188
Flinger Sleeve: 135796/52401270401
Gasket (Oil Inlet): 129119
Gasket (Oil Outlet): 129120
Gasket (Turbine Inlet): 409038-0000 (132040, 202873, 205396, 3500683, 1S4295, 9749, 210017-0000)(1900000003)
Gasket Kit: 318417
Heat Shield: 137570
Hexagon Bolt: 140319
Hexagon Head Screw: 314006 (Replaces 158567)
Journal Bearing: 142869/192871
Nozzle Ring: 147120 (5S3472)
O-Ring: 139051/139265
Oil Deflector: 137856
Pipe Plug: 24576
Piston Ring (Yellow): 125647
Repair Kit (4HD/HF): 183212
Repair Kit (4MD): 318357
Retaining Ring: 129533/134058/139052
Shaft Nut: 194118
Shim: 125648 (15189, 8M7167, 49160-42400, 144054-0000)(1250404250)(0.127 mm (0.005 in.) Thick)
Shim: 125649 (15190, 8M7168, 144055-0000, 49160-42500)(1250404251)(0.127 mm (0.005 in.) Thick)
Shim: 125650 (15191, 8M7169, 49160-42600, 144056-0000)(1250404252)(0.254 mm (0.010 in.) Thick)
Spacer Ring: 140029
Spacer Sleeve: 137016
Spacer: 137945
Thrust Bearing: 140964
Thrust Ring: 140963
Turbine Housing: 181932 (0R5412, 6N8453)
Turbine Wheel: 181480 (0R5390, 7S7759, 159750, 0R5389, 2S1530, 9M9933)(Ind. 93.2 mm, Exd. 112-113.2 mm, Trim 16.85, 13 Blades)
V-Band Nut: 130665
V-Band: 140153
Washer: 183482
Application:
1976-06 Caterpillar Earth Moving with D399 Engine
Caterpillar Generator Set with D399, SR4 Engine
Caterpillar Generator with SR4 Engine
Caterpillar Industrial with D399, SR4 Engine
Caterpillar Marine with D399 Engine
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
This is a BRAND NEW GENUINE BORGWARNER TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.
Fits the following:
Part Number: 182781
Interchangeable Number: 178051, 478051
OEM Number: 0R-5827, 0R5827, 2P-3176, 2P3176, 4N-4564, 4N4564, 6N-8460, 6N8460
Turbo Model: 4HD, 4HD-857
Brand: BorgWarner - 3K - Schwitzer
Engine: D399, SR4
Engine Manufacturer: Caterpillar
Fuel: Diesel
Angle α (Compressor Housing): 107°
Angle β (Turbine Housing): 90°
Bearing Housing Insert: 139053
Bearing Housing: 137568 (0R5399, 2S1309, 4N4042, 9M9929)(Oil Cooled)
CHRA: 157702 (310145, 0R5883, 4N4041, 6N8658, 157702R, 178141, 457702, 478141)
Compressor Housing: 143971 (5S3974)
Compressor Wheel: 140922 (139398)(5S3975)(Ind. 78.8 mm, Exd. 122 mm, Trim 7.56, 7+7 Blades, Super Back)
Filter Cup: 183188
Flinger Sleeve: 135796/52401270401
Gasket (Oil Inlet): 129119
Gasket (Oil Outlet): 129120
Gasket (Turbine Inlet): 409038-0000 (132040, 202873, 205396, 3500683, 1S4295, 9749, 210017-0000)(1900000003)
Gasket Kit: 318417
Heat Shield: 137570
Hexagon Bolt: 140319
Hexagon Head Screw: 314006 (Replaces 158567)
Journal Bearing: 142869/192871
Nozzle Ring: 147120 (5S3472)
O-Ring: 139051/139265
Oil Deflector: 137856
Pipe Plug: 24576
Piston Ring (Yellow): 125647
Repair Kit (4HD/HF): 183212
Repair Kit (4MD): 318357
Retaining Ring: 129533/134058/139052
Shaft Nut: 194118
Shim: 125648 (15189, 8M7167, 49160-42400, 144054-0000)(1250404250)(0.127 mm (0.005 in.) Thick)
Shim: 125649 (15190, 8M7168, 144055-0000, 49160-42500)(1250404251)(0.127 mm (0.005 in.) Thick)
Shim: 125650 (15191, 8M7169, 49160-42600, 144056-0000)(1250404252)(0.254 mm (0.010 in.) Thick)
Spacer Ring: 140029
Spacer Sleeve: 137016
Spacer: 137945
Thrust Bearing: 140964
Thrust Ring: 140963
Turbine Housing: 181932 (0R5412, 6N8453)
Turbine Wheel: 181480 (0R5390, 7S7759, 159750, 0R5389, 2S1530, 9M9933)(Ind. 93.2 mm, Exd. 112-113.2 mm, Trim 16.85, 13 Blades)
V-Band Nut: 130665
V-Band: 140153
Washer: 183482
Application:
1976-06 Caterpillar Earth Moving with D399 Engine
Caterpillar Generator Set with D399, SR4 Engine
Caterpillar Generator with SR4 Engine
Caterpillar Industrial with D399, SR4 Engine
Caterpillar Marine with D399 Engine
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
