NEW OEM BorgWarner T04B Turbo International Navistar Agricultural DT436 313101
SKU: 313101This is a BRAND NEW GENUINE BORGWARNER TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.
Fits the following:
Part Number: 313101
Interchangeable Number: 409000-0001, 409000-5001, 409000-5001S, 409000-0003, 409000-5003, 409000-5003S, 409570-0001, 409570-5001, 409570-5001S, 409570-0007, 409570-5007, 409570-5007S, 409570-0008, 409570-5008, 409570-5008S, 409570-0009, 409570-5009, 409570-5009S, 409570-0010, 409570-5010, 409570-5010S
OEM Number: 684549C91, 687117C91, 674997C91, 680099C91, 684238C91, 684238C91, 749265C91
Replacement Number: 409570-0010, 409570-5010, 409570-5010S, 409570-0016, 409570-5016, 409570-5016S
Turbo Model: T04B, T04B18
Manufacturer: BorgWarner - 3K - Schwitzer
Engine: DT360/429/436/466
Engine Manufacturer: Mavistar
Displacement: 7.6L, 7600 ccm, 6 Cylinders
Fuel: Diesel
Back Plate: 408045-0034 (5149542, 311708, 310010, 4N6863)(104244-0000, USE 408045-0051/408045-0051/408045-0006/408206-0002)(1100040360)
Bearing Housing: 430027-0051 (430027-0035, 193731, 186880, 186882)
CHRA: 408105-0157 (408105-5157S, 684243C91, 684244C91)
Compressor Wheel: 410514-0023 (310741)(Ind. 51.6 mm, Exd. 70. mm, Trm T, 8+8 Blades)
Gasket (Oil Inlet): 210023 (210023-0000, 147837, 210021, 215234, 55739, 3709737, 3500681, 3519762, 409266-0001, 409036-0000, 409026-0001, 52231586500)(1900000037)(Paper)
Gasket (Oil Outlet): 210021 (210023-0000, 147837, 210023, 215234, 55739, 3709737, 3500681, 3519762, 409266-0001, 409036-0000, 409026-0001, 52231586500)(1900000037)(Paper)
Gasket (Turbine Inlet): 407294-0001 (312617, 303031063)(Inox Steel)
Heat Shield: 409299-0000/409299-0001 (188276, 311943, 7N0012, 3524773B)
Repair Kit: 468100-0000 (1100040750, 3524796, 2W0716, 6N7236, 310063)
Turbine Housing A/R: 1.32
Turbine Wheel: 451309-0003 (446905-0007, 310207)(Ind. 74.2 mm, Exd. 64.7 mm, 11 Blades)(1100040436)
Applications:
International Agricultural N/D with Navistar DT360/429/436/466 Engine
International Harvester 1460 Combine with Navistar DT436 Engine
International Harvester 4166 Agricultural Tractor with Navistar DT436 Engine
International Harvester 433 Scraper with Navistar DT360/429/436/466 Engine
International Harvester 444 Scraper with Navistar DT360/429/436/466 Engine
International Harvester 540 Loader with Navistar DT466 Engine
International Harvester Dresser with Navistar DT466 Engine
International Harvester H80B Loader with Navistar DT466 Engine
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
