BorgWarner
NEW BorgWarner S1BG Turbo VM Forklift Truck Industrial HR494HPT 2.78L 316148
NEW BorgWarner S1BG Turbo VM Forklift Truck Industrial HR494HPT 2.78L 316148
SKU:316148
Regular price
$2,095.00
Regular price
Sale price
$2,095.00
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Orders ship Monday-Friday, usually within 24 hours of purchase.
International shipping subject to VAT and/or other import tax calculated during checkout.
BRAND NEW GENUINE BORGWARNER TURBOCHARGER
This is a BRAND NEW GENUINE BORGWARNER TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.
Fits the following:
Part Number: 316148
Interchangeable Number: 312193K, 312193, 312407, 53169886718, 53169706718, 53169706706, 312193K, 53169706718, 312193
OEM Number: 35242033G, 35242033F, 35242014A, 35242070F, 35242033F/G
Turbo Model: S1AG, S1BG
Brand: BorgWarner - 3K - Schwitzer
Engine: HR492HPT, HR494HPT
Displacement: 2.78L, 2780 ccm
Fuel: Diesel
Power: 72 kW/96 HP
Speed: 2600 RPM
Angle α (Compressor Housing): 316°
Angle β (Turbine Housing): 140°
Bearing Housing: 316147 (Oil Cooled)(1900011213C)
Turbine Wheel: 312880 (Ind. 46.99 mm, Exd. 40. mm, Trim 6.09, 12 Blades)(1252201435, 1100016215)
Compressor Wheel: 316102 (Ind. 39.9 mm, Exd. 48.3 mm, Trim 60, 6+6 Blades)
Back Plate: 315910 (196872)(1252201300, 1800016064)
Heat Shield: 311863 (1252201340, 2030016099)
Repair Kit: 318374 (1252201751, 5000030016)
Turbine Housing: 312381
CHRA: 316149
Compressor Cover: 312393
Actuator: 312569
Gasket (Turbine Inlet): 312746
Wastegate Settings (Pressure): 1.082-1.124 bar
Wastegate Settings (Lift Shaft): 0.38 mm.
NOTE:
- Complete replacement turbo. Internal parts not interchangeable.
- Replaces OE S1A 312193 and Aftermarket 312407.
- Replacement for OE S1A 312193 and Aftermarket 312407.
Application:
1989-12 VM Forklift, Truck, Industrial with HR494HPT Engine
1989-12 VM Various with HR492HPT Engine
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
This is a BRAND NEW GENUINE BORGWARNER TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.
Fits the following:
Part Number: 316148
Interchangeable Number: 312193K, 312193, 312407, 53169886718, 53169706718, 53169706706, 312193K, 53169706718, 312193
OEM Number: 35242033G, 35242033F, 35242014A, 35242070F, 35242033F/G
Turbo Model: S1AG, S1BG
Brand: BorgWarner - 3K - Schwitzer
Engine: HR492HPT, HR494HPT
Displacement: 2.78L, 2780 ccm
Fuel: Diesel
Power: 72 kW/96 HP
Speed: 2600 RPM
Angle α (Compressor Housing): 316°
Angle β (Turbine Housing): 140°
Bearing Housing: 316147 (Oil Cooled)(1900011213C)
Turbine Wheel: 312880 (Ind. 46.99 mm, Exd. 40. mm, Trim 6.09, 12 Blades)(1252201435, 1100016215)
Compressor Wheel: 316102 (Ind. 39.9 mm, Exd. 48.3 mm, Trim 60, 6+6 Blades)
Back Plate: 315910 (196872)(1252201300, 1800016064)
Heat Shield: 311863 (1252201340, 2030016099)
Repair Kit: 318374 (1252201751, 5000030016)
Turbine Housing: 312381
CHRA: 316149
Compressor Cover: 312393
Actuator: 312569
Gasket (Turbine Inlet): 312746
Wastegate Settings (Pressure): 1.082-1.124 bar
Wastegate Settings (Lift Shaft): 0.38 mm.
NOTE:
- Complete replacement turbo. Internal parts not interchangeable.
- Replaces OE S1A 312193 and Aftermarket 312407.
- Replacement for OE S1A 312193 and Aftermarket 312407.
Application:
1989-12 VM Forklift, Truck, Industrial with HR494HPT Engine
1989-12 VM Various with HR492HPT Engine
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
