New Garrett GT3267 Turbo Off-Highway 6.0L Perkins Darwin T6.60 452234-5001
New Garrett GT3267 Turbo Off-Highway 6.0L Perkins Darwin T6.60 452234-5001
SKU:452234-5001
Regular price
$1,199.00
Regular price
Sale price
$1,199.00
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Orders ship Monday-Friday, usually within 24 hours of purchase.
International shipping subject to VAT and/or other import tax calculated during checkout.
BRAND NEW GENUINE GARRETT TURBOCHARGER
This is a BRAND NEW GENUINE GARRETT TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.
Fits the following:
Part Number: 452234-5001
Interchangeable Number: 452234-0001, 452234-5001S, 452234-0002, 452234-5002, 452234-5002S
OEM Number: 02-201570, 02/201570, 02201570, 166-2881, 1662881, 2-201570, 2/201570, 2201570, 2674A090, 2674A091, 4222178M91, 500\356, 500356, U2674A090, U2674A091
Turbo Model: GT3267
Brand: Honeywell - Garrett
Engine: Darwin T6.60, T6.60
Engine Manufacturer: Perkins
Displacement: 6.0L, 5980 ccm, 6 Cylinders
Emission Standard: Euro 3
Fuel: Diesel
Power: 122 kW/165 hp
Angle α (Compressor Housing): 196°
Angle β (Turbine Housing): 0°
Back Plate: 436040-0004 (1300016139)
Bearing Housing: 447535-0003 (Oil Cooled)(1900011181)
CHRA: 436058-0004 (436058-5004S)(1000010391)
Compressor Housing: 436237-0013
Compressor Wheel: 434437-0005 (Ind. 46.2 mm, Exd. 67 mm, Trim 4.69, 6+6 Blades, Super Back)(1200016458)
Gasket (Oil Inlet): 210023 (210023-0000, 147837, 210021, 215234, 55739, 3709737, 3500681, 3519762, 409266-0001, 409036-0000, 409026-0001, 52231586500)(1900000037)(Paper)
Gasket (Oil Outlet): 210060 (409267-0003, 409267-0002, 210060-0000, 51914, 148062, 311585)(2475013)(Paper)
Gasket (Turbine Inlet): 409039-0000 (409039-0001, 210019, 2405022)(Inox Steel)(1900000006)
Gasket (Turbine Outlet): 210226 (2405066)(Stainless Steel)
Gasket Kit: 215096 (1900100300, 2090505315, JTC11319, XJTC11319)
Heat Shield: 447553-0006 (2030016048B)
Repair Kit: 740659-0007/709147-0001 (1102032750, 5000010173)
Stud Kit: 216019
Turbine Housing A/R: 0.78
Turbine Housing: 451225-0028/451225-0023
Turbine Wheel: 434444-0007 (Ind. 64 mm, Exd. 54.7 mm, Trim 73, 10 Blades)(1100016325)
Application:
Off-Highway with 6.0L Perkins Darwin T6.60 Diesel Engine
Power Unit with 6.0L Perkins T6.60 Diesel Engine
Truck with 6.0L Perkins T6.60 Diesel Engine
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
