NEW Garrett T04B98 Turbo Gen Set Detroit Diesel 4L71T 4.7L Engine 465242-5003SKU: 465242-5003
This is a BRAND NEW GENUINE GARRETT TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.
Fits the following:
Part Number: 465242-5003
Interchangeable Number: 465242-0003, 465242-5003S
OEM Number: 5106335, 05106335
Turbo Model: T04B98
Engine: 4L71TI, 4L71T
Engine Manufacturer: Detroit Diesel
Displacement: 4.7L, 4650 ccm, 4 Cylinders
Power: 208 HP
Speed: 1800 RPM
Angle α (Compressor Housing): 11.5°
Angle ß (Turbine Housing): 20°
Back Plate: 408045-0051 (311708, 312576, 408045-0034, 408045-0006, 408045-0035, 310010, 4N6863, 408206-0002, 104244-0000)(1100040360)
Bearing Housing: 430027-0021 (407285-0019, 430027-0051)(AR63781)(Oil Cooled)
CHRA: 408105-0192 (408105-5192S, 408105-0119, 8920889, 166198, 166198R, 24018, 466198)
Compressor Cover: 409295-0003 (8920891)
Compressor Wheel: 409826-0015 (8920890)(Ind. 58.42 mm, Exd. 70 mm, Trim 6.93, 6+6 Blades, Flat Back)
Gasket (Oil Inlet): 210023 (210023-0000, 147837, 215234, 55739, 3709737, 3500681, 3519762, 409266-0001, 409036-0000, 409026-0001, 52231586500)(1900000037)(Paper)
Gasket (Oil Outlet): 210021 (148062, 311496, 3519807, 413671-0000, 409037-0000)(1900000027)
Gasket (Turbine Inlet): 210140 (Stainless Steel)
Heat Shield: 409299-0001 (409299-0000) (ME078199, 5149546)(311943, 7N0012, 3524773B)
Repair Kit: 468100-0000 (3524796, 168984, 310063, 188006-0000)(1100040750)
Turbine Housing A/R: 1.14
Turbine Housing: 409302-0033 (8920892)
Turbine Wheel: 451309-0004 (407276-0006, 407276-0019, 410188-0003, 410188-0006, 410188-0037, 446905-0002, 446905-0005, 446905-0007, 446905-0010, 451309-0003)(T04B/E LHT)(Ind. 73.99 mm, Exd. 64.61 mm, Trim 10.79, 11 Blades)
1977- Generating Set, Various with Detroit Diesel 4L71T Engine
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
