NEW Garrett TA3107 Turbo CAT JCB Loader Backhoe Perkins CA4.236 3.9L 465778-5016

BRAND NEW GENUINE GARRETT TURBOCHARGER

This is a BRAND NEW GENUINE GARRETT TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.

Fits the following:

Part Number: 465778-5016
Interchangeable Number: 465778-0016, 465778-5016S, 465778-0017, 465778-5017, 465778-5017S, 465778-0020, 465778-5020, 465778-5020S
OEM Number: 02-101418, 02-101815, 02/101418, 02/101815, 02101418, 02101815, 0R-4543, 0R4543, 11996077, 2-101418, 2-101815, 2/101418, 2/101815, 210-1418, 2101418, 210-1815, 2101815, 267-4396, 2674396, 267-4397, 2674A397, 2674397, 2674A396, 500378, 500\378, 674A123, 9011996077
Turbo Model: TA3107
Manufacturer: Honeywell-Garrett

Engine: CA4.236
Engine Manufacturer: Perkins
Displacement: 3.9L, 3860 ccm, 4 Cylinders
Fuel: Diesel
Power: 76 HP
Speed: 2400 RPM

Back Plate: 409629-0004/409629-0006/409629-0001 (197340)(1100030300)
Bearing Housing: 430027-0022/430027-0025/430027-0029 (186879, 186881, 194230)(1100030450)(Oil Cooled)
CHRA: 409172-0045 (409172-5045S)
Compressor Wheel: 409096-0008/409096-0001 (197611, 103016-0000)(1100030401)(Ind. 60 mm, Exd. 40.5 mm, Trim 45, 6 Blades)
Gasket (Oil Inlet): 210023 (210023-0000, 147837, 210021, 215234, 55739, 3709737, 3500681, 3519762, 409266-0001, 409036-0000, 409026-0001, 52231586500)(1900000037)
Gasket (Oil Outlet): 210021 (148062, 311496, 3519807, 413671-0000, 409037-0000)(1900000027)
Gasket (Turbine Inlet): 409039-0000 (2405022)(Stainless Steel)
Gasket Kit: 215068
Heat Shield: 409627-0000 (103121-0000, 311131)
Repair Kit: 468139-0000 (1100030750)(Dynamic)
Turbine Housing A/R: 1.06
Turbine Wheel: 451310-0006/451310-0003 (314647)(1100030438)(Ind. 65 mm, Exd. 48.5 mm, Trim 56, 11 Blades)
Turbo Technology: Free Floating

Application:
Caterpillar 438C Backhoe Loader with CA4.236 Engine
JCB Backhoe Loader
Perkins Backhoe, Agricultural Tractor with CA4.236 Engine

*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
