K24 Turbo Volvo S60R V70R R-Line Engine R5 B5254T4 2.5L 53249887400

TURBOTURBOS REMANUFACTURED TURBOCHARGER

This is a TURBOTURBOS REMANUFACTURED TURBOCHARGER. This is an exact, direct fit replacement turbo.

Fits the following:

Part Number: 53249887400
Interchangeable Number: 5324-988-7400, 5324 988 7400, 53249707400, 5324-970-7400, 5324 970 7400, 53249987400, 5324-998-7400, 5324 998 7400
OEM Number: 30713137, 8602805, 8603298, 8677954
Turbo Model: K24.2474DXBAA6.GAAXM, K24-7400

Year: 2002-07
Engine: R-Line, B5254T4
Engine Manufacturer: Volvo
Displacement: 2.5L, 2521 ccm, 5 Cylinders
Fuel: Gasoline
Power: 220 kW/300 HP
Speed: 5500 RPM

Angle α (Compressor Housing): 260°
Angle β (Turbine Housing): 295°
Actuator: 58251104095
Back Plate: 53241515718
Bearing Housing: 53241500032
CHRA: 53247100517 (53247100517)
Compressor Cover: 53241015111
Compressor Wheel: (Outer Dia.: 62 mm, Ind. 45.8 mm, EAT (Extended Tip Technology))
Compressor Wheel: 53241232201
Repair Kit: 53247110021
Turbine Housing A/R: 6
Turbine Housing: (6² cm Area, Set Pressure: 7 bar @ 7 mm Lift)
Turbine Housing: 53241009031
Turbine Wheel: (Outer Dia.: 59 mm, Exd. 50 mm, Tip: 9 mm, Stub Shaft Dia.: 5.4 mm)
Turbine Wheel: 53241205006

NOTE:

- Intercooler.
- On compressor side, the R wheel is 45 mm outer diameter whereas RS2 is 48 mm.
- On turbine side, the R wheel is 48 mm outer diameter whereas the RS2 is 55 mm.

Application:
2002-07 Volvo S60R, V70R with R-Line R5 Engine

*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
