TBP4 Turbo Universal T3 T4 Journal Bearing Oil Cooling Wastegated 706284-5004SKU: F706284-5004R
This is a TURBOTURBOS REMANUFACTURED TURBOCHARGER. This is an exact, direct fit replacement turbo.
Fits the following:
Part Number: 706284-5004
Interchangeable Number: 706284-0004, 706284-5004S
OEM Number: 1118010S-CKAS, 1118010SCKAS
Turbo Model: TBP4
Displacement: 2-3L (Gasoline Engine), 4-6L (Diesel Engine)
Fuel: Gasoline, Diesel
Power: 500-600 HP
Actuator Pressure: 19.5 PSI @ 0.38 mm Travel
Compressor A/R: 0.50
Compressor Wheel: (Ind. 52.78 mm, Exd. 76.20 mm, Trim 48)
Flange (Compressor): T4
Flange (Manifold): T3
Turbine A/R: 0.84 Turbine Wheel: (Ind. 56.01 mm, Exd. 68 mm, Trim 57)
Universal for 2-3L Gasoline Engine, 4-6L Diesel Engine
Various with CA6110ZLA1 Engine
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
