NEW K03 Turbocharger Audi S4 A6 AGB AJK ARE BES Engine 2.7L 53039700016 TurboSKU: TP02-0036-09
This is a NEW DIRECT REPLACEMENT TURBOCHARGER. This is an exact, direct fit replacement turbo.
NOTE: This 2.7L engine uses two turbos for boosting. This is the left side turbocharger and the right side is 53039700017.
Fits the following:
Part Number: 53039880016
Previous Version: 5303-988-0016, 5303 988 0016
OE Number: 078145701S, 078145701R, 078145701H, 078145701L, 078145703D, 078145703H, 078145703L, 078145703R, 078145703S, 078145703C, 078145703B
Description: Audi A6 2,7 T (C5) Left
Manufacturer Part Number: 53039700016, 5303-970-0016, 5303 970 0016
CHRA: 53037100509 (5303-710-0509)(1302003909)
Turbo Model: K03-1870EXA4.82KCAXK
Engine: AJK, ARE, BES, AGB
Displacement: 2.67L, 2671 ccm, V6 Cylinders
RPM Max: 6000
Angle α (compressor housing): 217.1°
Angle β (turbine housing): 105.2°
Bearing Housing: 53041500009 (53041500006, 53041500015, 53041500017)(1302003460, 203070002)(Water Cooled)
Turbine Wheel: 53031205029 (53031205000, 53031205002, 53031205008, 53031205010, 53031205012, 53031205013, 53031205017, 53031205023, 53031205025, 53031205027, 5303120-5037)(Ind. 45.03 mm, Exd. 37.82 mm, 11 Blades)(1302003438, 201050005)
Comp. Wheel: 53031232011 (53031232003, 53031232004)(Ind. 31.45 mm, Exd. 44.96 mm, 4+4 Blades, Superback)(1302003401)
Back plate: 53041515703 (1302003303)
Heat shield Number: 53031652000 (1302003340, 206030001)
Repair Kit: 53037110000 (706832-0001)(1302003752)
Turbine Housing: 53031008008
Compressor Cover: 53031015005
Turbine Housing AR: 4
NOTE: Intercooler; watercooled bearing housing; Left side
1997-01 Audi A6 with AJK, ARE, BES, AGB Engine
1997-01 Audi A6 Allroad with AJK, ARE, BES, AGB Engine
1997-01 Audi S4 with AJK, ARE, BES, AGB Engine
TurboTurbos Part Number: TP02-0036-09
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
