NEW HX80 Turbo Perkins Genset Cummins KTA19 KTA50 Engine 3594117SKU: TP05-0088-28
This is a NEW DIRECT REPLACEMENT TURBOCHARGER. This is an exact, direct fit replacement turbo.
Fits the following:
Part Number: 3594117
Interchangeable Number: 2882091, 3767941, 3803474, 4033471
OEM Number: 3594118, 3594119, 3594120, 3594121
Turbo Model: HX80, HX80-3851Z/B40D3
Engine: KTA19, KTA19-G3, KTA38-G5, KTA50
Engine Manufacturer: Cummins
Power: 450/650 HP
Angle α (Compressor Housing): 199°
Angle ß (Turbine Housing): 22.5°
Back Plate: 3527348
Bearing Housing: 3523429
CHRA: 3545464 (3594200)
Compressor Wheel: 3533703 (Ind. 90.96 mm, Exd. 141.05 mm, Trim 41, 8/8)
Gasket (Oil Outlet): 210018 (129120)
Gasket (Turbine Inlet): 409038-0000 (132040, 52231083002)
Heat Shield: 3519783
Repair Kit: 4027970 (4027974, 3575236, 3545647, 4027966) (1152105750, 1152105756)
Turbine Wheel: 3521033 (Ind. 129 mm, Exd. 95.4 mm)(1152105435)
1990-01 Genset Various with Cummins KTA50 Engine
1990-03 Perkins Genset Various with Cummins KTA50 Engine
TurboTurbos Part Number: TP05-0088-28
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
Any questions or concerns, please feel free to email or call us.
For our Warranty / Return Policy, please see our Policies at the top of the website.
