NEW HE500VG Short Turbo Truck Detroit Diesel Series 60 14.0L 3786234 5352845SKU: TP05-0217-37
This is a NEW DIRECT REPLACEMENT TURBOCHARGER. This is an exact, direct fit replacement turbo.
NOTE: This listing is for a Short Turbo and does not come with electrical actuator.
Fits the following:
Part Number: 5352845
Interchangeable Number: 2836825, 2836826, 3781168, 3781169, 378623400, 378623400H, 378623400HX, 3786234H, 3786234HX, 3792071, 3798597, 4047269, 5329513, 5352846, 5498208
OEM Number: 19514480D, 23536422, 23536802, 23539062, 23539570, 3786234, 3792069, 4045291, 4047598, AP80055, E23536422, E23539062, E23539570, R23536422, R23539062, R23539570
Serial Number: 1209197011
Turbo Model: HE500VG, HE531VE
Engine: Series 60 (VGT) on EPA07
Engine Manufacturer: Detroit Diesel, MTU Detroit Diesel
Displacement: 14.0L, 14000 ccm
Angle α (Compressor Housing): 194°
Angle β (Turbine Housing): 90°
Actuator Installation Kit: 4031365 (20837312, 23537048, 403136500H, 4031365H)
Actuator Kit: 4034121 (3787580, 3787582, 4032244, 403412100, 403412100H, 4034121H, 23537677, E23537677, R23537677, 4034120H, AP80082, 4042309, 5352847)(12 Volts)
Bearing Housing: (Oil cooled)
CHRA: 4034440 (4034440H)
Compressor Wheel: 4035068 (2836825)(Ind. 65.19 mm, Exd. 98.61 mm, Trim 6.30, 7+7 Blades, Super Back)
Gasket Kit: 3545576 (201049, 3519763)
Nozzle Ring Assembly: (1154500990)
Repair Kit: (1154500755)
Turbine Housing A/R: VI EGR
Turbine Wheel: 4042581 (Ind. 83.99 mm, Exd. 69.97 mm, 12 Blades)(1154055438, 1100016492)
2004-14 Daimler Fire Truck (Class 3-8), Various with Detroit Diesel Series 60 Engine
Kenworth, Peterbilt, Freightliner with Detroit Diesel Series 60 Engine
TurboTurbos Part Number: TP05-0217-37
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
